Research and development, production, and sales of intelligent equipment for automatic welding machine.
Automatic Welding Oscillator
HBQ-60-Ⅱ is a kind of universal welding equipment, designed for oscillating welding torch along the seam from side to side to increase weld width, and improve forming and productivity. lt's mainly used in MIG/MAG/TIG welding processes. Up to 16 sets of welding parameters can be preset in control, and each set includes oscillation speed, oscillation range, center position, stay time etc,local or remote control just in your choice.
Options: power box, torch holder etc.
JBQ-A is a kind of universal welding equipments, full digital control, designed for oscillating welding torch along the seam from side to side to increase weld width, and improve forming and productivity. It's mainly used in MIG/MAG/TIG welding processes to weld corner weld and big groove bull weld. Up to 16 sets of welding parameters can be preset in control, and each set includes oscillation speed, oscillation range, center position, stay time etc, local or remote control just in your choice.
Options: power box etc.
CBQ- 1 is a kind of universal welding equipment, designed for oscillating arc along the seam from side to side to increase weld width and improve forming. Stir welding poor to increase joint strength.It's mainly used in TIG process, Oscillation frequency.oscillation range, slay lime are all in control, and also can be connected with PLC.
|
Speed |
0.1-3.0m/min. |
|
Range |
0-30mm |
|
Adjustment |
0-60mm |
|
Dwell time |
0-5.0s |
|
Max. linear speed |
4m/min(160 arm) |
|
Range |
±10° |
|
Accuracy |
0.1° |
|
Dwell time |
0-5.0s |
|
Frequency |
0.3-7.9HZ |
|
Range |
1-100% |
|
Magnetic field strength |
100-1000 Gauss |
|
Dwell time |
0-2.0s |
Precision Welding Improvement Solution
Enhance your welding precision and efficiency with our Welding Oscillator featuring adjustable linear and angle oscillation, magnetic field strength control, and high accuracy. With a range of 0-30mm and a dwell time of 0-5.0s, this oscillating tool ensures you achieve perfect welds every time. Increase productivity and quality with the speed and frequency controls, making welding tasks easier and more consistent.
Precision, Consistent, Efficient, Versatile
The Welding Oscillator features a linear, angle, and magnetic oscillator for precise weld placement and control. With a speed range of 0.1-3.0m/min and an adjustable range of 0-30mm, users can easily customize their welding process. The oscillator also offers accuracy up to 0.1° and a frequency range of 0.3-7.9HZ, ensuring high-quality welds with consistent results.
Precision Welding Oscillator Technology
The Welding Oscillator features a range of speed adjustments from 0.1 to 3.0m/min, allowing for precise control during welding operations. With a range of ±10° and an accuracy of 0.1°, this oscillator ensures precise and consistent welds every time. The magnetic field strength can be adjusted from 100 to 1000 Gauss, providing versatility for different welding needs.
◎ Versatile Speed Adjustments
◎ Accurate Control
◎ Magnetic Field Strength
